J5Create Powerful JCD381 USB-C Dual HDMI Mini Dock – Expand Your Workspace with 4K Display, Ethernet & SuperSpeed USB

SKU: JCD381
In Stock
10,519 Original price was: ₹10,519.8,765Current price is: ₹8,765. (with GST)
In Stock
Total:

Turn your USB-C port into a full workstation with the J5Create JCD381 Dual HDMI Mini Dock. Experience seamless dual display via HDMI™, fast file transfer with USB™ 3.0, secure wired networking via Gigabit Ethernet, and USB-C® Power Delivery 2.0 charging – all packed in a sleek, champagne metallic design. Perfect for remote work, hybrid offices, and high-efficiency setups.

  • Connect 2 displays (4K + 2K) via dual HDMI™

  • USB-C® PD 2.0 charging support up to 60W

  • Gigabit Ethernet for reliable wired networking

  • 2 x USB™ 3.0 ports for high-speed peripherals

  • Small, compact, and travel-ready

  • Product availability is dynamic. Final dispatch date will be confirmed after order placement.

Other people want this. 6 people have this in their carts right now.

Description

The J5Create JCD381 USB-C™ Dual HDMI™ Mini Dock transforms your USB-C® laptop into a powerful, multi-functional workstation in seconds. Whether you’re a creator, corporate professional, or remote worker, this pocket-sized hub ensures you’re always connected, charged, and productive—no matter where you are.

J5Create Dual HDMI USB-C Dock

Key Features

  • Dual HDMI™ Display Expansion: Add one 4K display and one 2K/Full HD display to your setup. Ideal for multitasking, streaming, editing, or presenting.

  • USB-C® Power Delivery 2.0: Charge your USB-C® laptop or mobile device while using the dock. Supports up to 60W charging pass-through.

  • Gigabit Ethernet: Enjoy stable, fast wired internet for lag-free video calls, gaming, and secure downloads.

  • Dual USB™ 3.0 Ports: SuperSpeed USB™ with transfer speeds up to 5 Gbps – ideal for keyboards, mice, external drives, or USB headsets.

  • Sleek, Heat-Reducing Design: Engineered in aluminum with champagne metallic finish and built-in thermal management for 24/7 usage.

  • Cutting-Edge Compatibility: Works with most modern USB-C™ laptops, including Windows, macOS, and Chrome OS™ systems.

  • Travel-Ready: Weighs just 113.5g with a short 7.8” integrated cable for hassle-free mobility.

Display Performance

  • Dual Display Setup:

    • HDMI™ 1: 4K (3840 x 2160 @ 30Hz)

    • HDMI™ 2: 2K (2048 x 1152) or 1080p (1920 x 1080 @ 60Hz)

  • Single Display:

    • Up to 3840 x 2160 @ 30Hz

  • Extend or mirror screens based on your OS capabilities.

Ports & Interfaces

  • 1 x USB-C® Power Delivery 2.0 Input (Up to 60W)

  • 2 x HDMI™ Outputs

  • 2 x USB™ 3.0 Type-A Ports (5 Gbps)

  • 1 x RJ45 Gigabit Ethernet Port

System Requirements

  • Operating System: Windows® 10+, macOS® 10.14+

  • Hardware:

    • USB-C® port with DisplayPort™ Alt Mode & Power Delivery

    • Recommended:

      • For Office Use: Intel® Core™ i3, 2 GB RAM

      • For 2K Video: Intel® Core™ i5, 4 GB RAM

      • For Dual Display or 4K: Intel® Core™ i7, 8 GB RAM

Note: macOS® and Windows® require driver installation. Windows® will auto-install with network access and admin rights.

Power Specifications

  • Input Voltage: Up to 20V / Current: 3A

  • Output Voltage: Up to 20V / Current: 3A

  • Power Consumption: ≤ 450 mA

  • PD Pass-Through: Up to 60W charging to host laptop

Build & Dimensions

  • Material: Aluminum

  • Color: Champagne Metallic

  • Cable Length: 7.8 in. (198.12 mm)

  • Dimensions: 5.1″ x 2.1″ x 0.6″ (130 x 54 x 15 mm)

  • Weight: 4.00 oz (113.5g)

Thermal & Environmental Tolerance

  • Operating Temp: 32°F to 98°F (0°C to 37°C)

  • Storage Temp: 14°F to 140°F (-10°C to 65°C)

  • Humidity: <85%, non-condensing


Package Contents

  • 1 x JCD381 USB-C® Dual HDMI™ Mini Dock

  • 1 x Quick Installation Guide

Country of Origin

Made in Taiwan

Importer

Creative Peripherals & Distribution Ltd., Mumbai, India

Warranty Information

2-Year Limited Manufacturer Warranty

1. Product Features & Functions

Q1. What does the JCD381 USB-C™ Dual HDMI Mini Dock do?
A: It expands a USB-C™ port into two HDMI™ display outputs, two USB™ 3.0 ports, Gigabit Ethernet, and a USB-C® PD charging port—all through a single compact device.

Q2. Can I connect two monitors at once?
A: Yes, the adapter supports dual HDMI™ outputs: one up to 4K @ 30Hz and the other up to 2K @ 60Hz.

Q3. Does this dock support Power Delivery charging?
A: Yes, it supports USB-C® Power Delivery 2.0, delivering up to 60W to charge your laptop or phone.

Q4. Can I charge my mobile phone with this dock?
A: Yes, the USB-C® PD port can charge supported smartphones using a USB-C® power adapter.

Q5. Does it have any USB-A ports?
A: Yes, there are two USB™ 3.0 Type-A ports with transfer speeds up to 5 Gbps.

Q6. Does the dock support Ethernet?
A: Absolutely. It features a Gigabit Ethernet port for high-speed, stable internet connectivity.

Q7. Can I use all the ports at the same time?
A: Yes, all ports can be used simultaneously as long as your device supports the required power and data throughput.

Q8. Is hot-swapping supported?
A: Yes, you can plug and unplug peripherals without rebooting your system.

Q9. What material is the dock made of?
A: The JCD381 has a premium aluminum enclosure with a champagne metallic finish.

Q10. Does it support audio output?
A: Yes, HDMI™ 2.1 supports 2.1 channel audio output.

💻 2. Compatibility & Connectivity

Q11. Is this dock compatible with macOS?
A: Yes, it supports macOS® 10.14 and above. Driver installation may be required.

Q12. Does it work with Windows laptops?
A: Yes, Windows® 10 and later are supported. Drivers will auto-install with internet access.

Q13. Is it compatible with Chromebooks?
A: If the Chromebook supports USB-C™ with DisplayPort™ Alt Mode, it will work.

Q14. Can I use this with a MacBook Pro or Air?
A: Yes, it is fully compatible with USB-C™ equipped MacBooks.

Q15. Will it work with Dell, HP, Lenovo, or ASUS laptops?
A: Yes, as long as the laptop has a USB-C™ port with DisplayPort™ Alt Mode and Power Delivery.

Q16. Can I use this dock with an Android tablet or phone?
A: Only if your device supports USB-C™ DisplayPort™ Alt Mode. Compatibility varies by model.

Q17. Is it compatible with iPad Pro?
A: Yes, the newer iPad Pro models with USB-C™ support basic functionality.

Q18. Will it work with older USB-A laptops?
A: No, this dock is specifically designed for USB-C™ ports.

Q19. Does the dock require any software or drivers?
A: For Windows and macOS, drivers are required. Windows installs them automatically if the device has internet and admin rights.

Q20. Can I use this with a docking station or hub?
A: It's best used directly with a USB-C™ port for optimal performance.

🎮 3. Display, Speed & Performance

Q21. What’s the max resolution for a single display?
A: It supports up to 3840 x 2160 (4K) @ 30Hz for a single monitor.

Q22. What resolutions do both HDMI ports support when used together?
A: One HDMI port supports 4K @ 30Hz, and the other supports 2K (2048 x 1152) or Full HD (1080p) @ 60Hz.

Q23. Does it support 60Hz on both displays?
A: No, only the second HDMI™ port supports 60Hz at lower resolutions. 4K is limited to 30Hz.

Q24. Is the image quality suitable for video editing?
A: Yes, it provides excellent clarity and smooth visuals, ideal for content creators.

Q25. Will it work for gaming?
A: Casual and office gaming is fine. For serious gaming at high frame rates, 60Hz+ support is preferred.

Q26. What is the max data transfer speed?
A: The USB™ 3.0 ports support up to 5 Gbps transfer speeds.

Q27. Is internet speed affected when using Ethernet?
A: No, the Gigabit Ethernet port supports up to 1000 Mbps for fast, reliable connectivity.

Q28. Does the dock heat up?
A: It may become warm during heavy usage, but it has a heat-dissipating aluminum body to prevent overheating.

Q29. Can I watch 4K content through this dock?
A: Yes, provided your monitor and system support 4K @ 30Hz.

Q30. Does it support audio-video sync over HDMI™?
A: Yes, the HDMI™ 2.1 interface ensures smooth AV sync for most applications.

🛠 4. Build Quality, Power & Packaging

Q31. What is the color of the dock?
A: It comes in a stylish champagne metallic finish.

Q32. What’s the dock made of?
A: It is made from high-grade aluminum for durability and thermal control.

Q33. How long is the built-in cable?
A: The integrated USB-C™ cable is 7.8 inches (198 mm) long.

Q34. What is the weight of this dock?
A: It weighs just 113.5 grams, making it ideal for travel.

Q35. What is the size of this product?
A: Dimensions are 5.1” x 2.1” x 0.6” (130 mm x 54 mm x 15 mm).

Q36. What’s in the box?
A: 1 x JCD381 USB-C® Mini Dock and 1 x Quick Installation Guide.

Q37. What is the warranty period?
A: It comes with a 2-Year Limited Manufacturer Warranty.

Q38. What is the country of origin?
A: This product is made in Taiwan.

Q39. Who is the importer in India?
A: Creative Peripherals & Distribution Ltd., based in Mumbai.

Q40. Is the product BIS certified?
A: This is an original, globally certified product imported through authorized channels.
