Fuji Electric Finch PW 3kVA Double Conversion Online UPS – Reliable Power for ATMs, Banks & Business-Critical Systems

Description

The Fuji Electric Finch PW 3kVA Online UPS is engineered to deliver uncompromising power quality and uptime for business-critical environments such as banking branches, ATM counters, commercial offices, and server rooms. Built using double conversion online technology, this UPS ensures that even the most sensitive electronic systems receive a consistent, clean power supply—free from interruptions, noise, or voltage fluctuations.

✅ Why Finch PW 3kVA?

1. True Online Double Conversion UPS
   Offers constant voltage and frequency regulation through continuous AC-to-DC and DC-to-AC conversion. Ensures connected devices are isolated from power disturbances like spikes, surges, and brownouts.

2. High Input Power Factor of 0.99
   With a nearly perfect power factor, Finch PW optimizes power usage, reduces input current draw, and minimizes distortion on the electrical line, resulting in greater efficiency.

3. Extended Backup Capability with External Batteries
   Finch PW supports 6 to 8 external batteries and offers adjustable charging current (1A to 6A). With additional chargers, it can meet extended runtime demands for long backup situations like remote ATMs or critical data storage.

4. Optional Inbuilt Isolation Transformer
   Protects your connected loads by electrically separating them from utility power and mitigating risks such as noise, leakage current, and electrical faults.

5. Hot Standby Configuration
   Delivers enhanced reliability by keeping a redundant unit ready to take over in case the primary UPS fails—critical for 24/7 uptime environments.

6. Automatic Bypass Function
   Transfers load to utility power seamlessly in the event of internal UPS failure or overload, without service interruption.

7. Smart LCD Panel with Real-Time Indicators
   Features indicators for:

   • Load Level

   • Battery Level

   • AC Mode / Battery Mode

   • Bypass Mode / Fault Alerts

8. Battery Cold Start Functionality
   Powers up even during total blackouts without the need for utility power.

9. Compatible Across Wide Voltage & Frequency Ranges

   • Input Range: 110–300V AC

   • Input Frequency: 40–70Hz

   • Output Voltage: 200V/208V/220V/230V/240V selectable

   • Output Frequency: 50Hz (battery mode)

10. Extensive Protection Mechanisms

    • Under/Over Voltage

    • Overload

    • Short Circuit

    • Over Temperature

    • Line Noise

    • EMI/RFI

    • Sag/Spike

    • Deep Discharge & Battery Overcharge Protection

🏆 Certifications & Quality Assurance

• BIS Certified

• ISO 9001, ISO 14001, ISO 45001 Compliant

• Built as per IEC 62040-1, 2, 3 standards

📦 Ideal Use Cases

• Banking Terminals, ATMs

• Data Centres & Server Rooms

• Point-of-Sale & Billing Systems

• Medical Equipment (non-life support)

• Light Industrial Controls

Technical Specifications

System Requirements / Compatibility

• Devices: ATMs, POS, Network Routers, Servers, Medical Equipment

• Compatible Operating Environment: Industrial, Banking, Commercial

• External Battery Bank required (not included)

Box Contents

• 1 × Fuji Electric Finch PW 3kVA Online UPS (Tower)

• 1 × User Manual

• 1 × USB Cable

• 1 × RS-232 Configuration Cable

• Note: Battery and Cables for Battery Bank sold separately

Country of Origin + Importer / Manufacturer

• Country of Origin: India

• Manufacturer: Fuji Electric Co., Ltd.

• Website: www.fujielectric.com

Warranty Information

• 1 Year Standard Manufacturer Warranty
